74
4. Using the Viewer
4. Press the ▶ button to select“USB1” and press the
ENTERbutton.
The“USB1”thumbnailscreenwillbedisplayed.
TIP:
• Formoreinformationaboutthumbnailscreen,seepage79.
5. Usethe▲▼◀ or ▶buttontoselectanicon.
• The→(arrow)symbolontherightindicatesthereare
morepages.pressingthePAGE▽(pagedown)button
willshowthenextpage:pressingthePAGE△ (page up)
will show the previous page.
6. PresstheENTERbutton.
Operationvariesdependingontheselectedle.
•Stillimage
Theselectedslidewillbedisplayed.
The ◀ or ▶buttoncanbeusedtoselectthenext(right)
slideortheprevious(left)slideinthethumbnailscreen.
• PressingtheENTERbuttonwilldisplaythecontrolbar
with which is used to select or rotate an slide.(→ page
80)
