3. Convenient Features

 Storing Changes for Lens Shift, Zoom, and Focus [LENS

MEMORY]

TheadjustedvaluescanbestoredinprojectormemorywhenusingtheLENSSHIFT,ZOOMandFOCUSbuttonsof

theprojectorortheremotecontrol.Adjustedvaluescanbeappliedtothesignalyouselected.Thiswilleliminatethe

needtoadjustlensshift,focus,andzoomatthetimeofsourceselection.Therearetwowaystosaveadjustedvalues

forlensshift,zoom,andfocus.

Functionname Description page

REF.LENSMEMORY Adjustedvaluescommontoalltheinputsignals.

Ifnoadjustedvaluesarestoredin[LENSMEMORY],thevaluesstored

in[REF.LENSMEMORY]willbeappliedforlensadjustment.

→page121

LENSMEMORY Adjustedvaluesforeachinputsignal.

Usetheadjustedvaluesforthesignalwithadifferentaspectratioor

resolution.Theadjustedvaluescanbeappliedatthetimeofsource

selection.

→page112

NOTE:

• TheNP25FLlensdoesnotsupporttheLensMemoryfunction.

• Besuretoperform[CALIBRATION]afterreplacementofthelens.

Usage Example

Whenyouwishtodisplayonascreenhavinga4:3aspectratioanNTSCorother4:3aspectratiosignalandan

SXGAorother5:4aspectratiosignal:

Performshift,focus,andzoomadjustmentstosettheverticalscreensizeoftheverticallytall5:4aspectratiosignal

tostandard.

Both4:3aspectratiosignalsand5:4aspectratiosignalscannowbedisplayed.

Notethatwiththeseshift,focus, and zoomadjustments,the4:3aspectratio signal will become smaller on the

screen.

Toeliminatethissizereduction,adjusttheshift,focusandzoomtotheoptimumconditionforeachofthe4:3aspect

ratiosignalandthe5:4aspectratiosignal.

Memory(storage)ofeachofthesevalueswillpermitprojectionatanoptimumconditionuponsignalswitching.

To store your adjusted values in [REF. LENS MEMORY]:

1. PresstheMENUbutton.

 Themenuwillbedisplayed.

2. Pressthe▶buttontoselect[SETUP]andpresstheENTERbutton.

3. Pressthe▶buttontoselect[INSTALLATION(1)].
