2. Projecting an Image (Basic Operation)

CAUTION

• Performtheadjustmentfrombehindorfromthesideoftheprojector.Adjustingfrom

thefrontcouldexposeyoureyestostronglightwhichcouldinjurethem.Therear

ventsoftheprojectormaybecomeheatedduringnormalprojectoroperation.Use

cautionwhenadjustingthetiltfootontherearside.

• Keephandsawayfromthelensmountingportionwhilethelensshiftisinoperation.

Failuretodosocouldresultinhandsbeingpinchedbythemovinglens.

Tilting the projector

Theprojectormustbeplacedsquaretothescreenotherwisekeystonedistortionmayappearonthescreen.Thissec-

tionprovidesexplanationonhowtoplacetheprojectorperpendiculartothescreenwhenviewedfromtheside.

1. Lowerthefrontandbacktiltfeet.

2. Usethehorizontaladjustmentknobtonelytilttheprojectorsothattheprojectorissettobeparallelwith

thescreen.

 Makesurethatthetopedgeoftheimageisparallelwiththebottomedgeoftheimage.

 Adjustablerange:4°

Screen

Parallel

Clockwise

Counter-

clockwise

Horizontaladjustmentknob

3. Rotatethetwofronttiltfeettoadjusttheheighttokeeptheprojectorlevelsothatthetopedgeofthescreen

isparallelwiththetopedgeoftheprojectedimage.

 Adjustablerange:1.8°

Screen

Parallel

Lower

Raise

Front tilt foot
