73
4. Using the Viewer
❸ Projecting images stored in a USB memory device
ThissectionexplainsthebasicoperationoftheViewer.
TheexplanationprovidestheoperationalprocedurewhentheViewertoolbarissettothefactorydefault.
Preparation:BeforestartingtheViewer,storeimagestotheUSBmemoryusingyourcomputer.
Starting the Viewer
1. Turnontheprojector.(→page16)
2. InserttheUSBmemoryintotheUSBportoftheprojec-
tor.
NOTE:
• DonotremovetheUSBmemoryfromtheprojectorwhileit’sLED
ashes.Doingsomaycorruptthedata.
TIP:
YoucanaUSBmemoryinserttheprojectorwhenthedrivelistscreen
is displayed.
3. PresstheSOURCEbuttontoselect[VIEWER].
ApressoftheSOURCEbuttonwilldisplaythesourceselect
screen.
AfewmorepressesoftheSOURCEbuttonwilldisplaythe
drive list screen.
Anotherwaytoselect[VIEWER]istopresstheVIEWER
buttonontheremotecontrol.
TIP:
• Formoreinformationaboutthedrivelistscreen,seepage77.
• Todisplaygraphicsinasharedfolder,seepage85; to display still
imagesormovielesinamediaserver,seepage89.
