31
2. Projecting an Image (Basic Operation)
Turning off the Projector
To turn off the projector:
1. First,pressthe (POWER)buttonon theprojector
cabinetorthePOWEROFFbuttonontheremotecon-
trol.
The[POWEROFF/AREYOUSURE?/CARBONSAV-
INGS-SESSION0.000[g-CO2]]messagewillappear.
2. Secondly, press the ENTER button or press the
(POWER)orthePOWEROFFbuttonagain.
Thelampwillturnoffandtheprojectorwillgointostandby
mode.Wheninstandbymode,thePOWERindicatorwill
lightorangeandtheSTATUSindicatorwilllightgreenwhen
[NORMAL]isselectedfor[STANDBYMODE].
3. PressthemainpowerswitchtotheOFFposition(O).
ThePOWERindicatorwillgooffandthemainpowerwill
turn off.
PowerOn
Steady blue light
Standby
Steady orange light
Press twice
