2. Projecting an Image (Basic Operation)
Adjusting with the remote control
1. PresstheLENSSHIFTbutton.
TheLensShiftscreenwillbedisplayed.
2. Pressthe▼▲◀ or ▶button.
Use the ▼▲◀▶buttonstomovetheprojectedimage.
TIP:
• Thediagrambelowshowsthelensshiftadjustmentrangeforthedesktopfront.Toraisetheprojectionpositionhigherthanthis,
usethetiltfeet.(→ page 22)
1V
1H
0.2H 0.2H
0.55V
0.4V
Height of projected image
Widthofprojectedimage
