Asus rog rampage iv black edition/ac4 [115/222] Chapter 3
![Asus rog rampage iv black edition/ac4 [115/222] Chapter 3](/views2/1159832/page115/bg73.png)
ASUS RAMPAGE IV BLACK EDITION
3-25
Chapter 3
Execute Disable Bit [Enabled]
[Enabled] Enables the No-Execution Page Protection Technology.
[Disabled] Forces the XD feature ag to always return to zero (0).
Intel
®
Virtualization Technology [Disabled]
[Enabled] Allows a hardware platform to run multiple operating systems separately
and simultaneously, enabling one system to virtually function as several
systems.
[Disabled] Disables this function.
CPU Power Management Conguration
Enhanced Intel SpeedStep Technology [Auto]
This item allows you to enable or disable the Enhanced Intel SpeedStep Technology
that helps decrease average power consumption and decrease average heat
production.
Conguration options: [Auto] [Disabled] [Enabled]
Turbo Mode [Enabled]
This item allows you to enable or disable the Turbo Mode that helps processors to
run faster the the base operating frequency if it is operating below power, current, and
temperature specication limit.
Conguration options: [Disabled] [Enabled]
CPU C states [Auto]
This item allows you to enable or disable the CPU C states.
Conguration options: [Auto] [Disabled] [Enabled]
The following items only appears when you set the CPU C states to [Enabled].
CPU C1E [Enabled]
Conguration options: [Disabled] [Enabled]
CPU C3 Report [Disabled]
Conguration options: [Disabled] [Enabled]
CPU C6 Report [Enabled]
Conguration options: [Disabled] [Enabled]
Package C State limit [Auto]
Conguration options: [Auto] [C0] [C2] [C6] [C7] [No Limit]
