Asus rog rampage iv black edition/ac4 [78/222] Power esata 6g

2-12

Chapter 2: Basic Installation

Chapter 2

2.1.9 Wi-Fi antenna installation

Installing the ASUS 2T2R dual band W-Fi antenna

Connect the bundled ASUS 2T2R dual band Wi-Fi antenna connector to the Wi-Fi ports at

the back of the chassis.

POWER eSATA 6G

S/PDIF

USB3.0

USB BIOS Flashback

USB3.0

REAR

SPK

CTR

BASS

LINE

FRONTMIC IN

IO Shield

• Ensure that the ASUS 2T2R dual band Wi-Fi antenna is securely installed to the Wi-Fi

ports.

• Ensure to install the Bluetooth and Wi-Fi driver before installing the Wi-Fi GO!

software.
