Asus rog rampage iv black edition/ac4 [80/222] Motherboard rear and audio connections

2-14

Chapter 2: Basic Installation

Chapter 2

2.3 Motherboard rear and audio connections

2.3.1 Rear I/O connection

Rear panel connectors

1. PS/2 mouse and keyboard port

2. Clear CMOS button

3. USB 2.0 ports 3 and 4 (The ROG Connect port is the port on top.)

4. USB 3.0 ports 3 and 4

5. Intel

LAN (RJ-45) port**

6. Wi-Fi 802.11 a/b/g/n/ac Bluetooth V4.0*

7. USB 2.0 ports 1 and 2

8. ROG Connect button

USB 3.0 ports 1 and 2

10. External SATA 6.0 Gb/s ports 1 and 2

11. USB 3.0 ports 5 and 6

12. Audio I/O ports with Optical S/PDIF Out port***

*, **, and ***: Refer to the tables on the next page for Bluetooth/Wi-Fi module LEDs, LAN port LEDs, and audio port

denitions.
