ASUS RAMPAGE IV BLACK EDITION

3-41

Chapter 3

CSM (Compatibility Support Module)

Allows you to congure the CSM (Compatibility Support Module) items to fully support the

various VGA, bootable devices and add-on devices for better compatibility.

Launch CSM [Enabled]

[Auto] The system automatically detects the bootable devices and the add-

on devices.

[Enabled] For better compatibility, enable the CSM to fully support the non-UEFI

driver add-on devices or the Windows

UEFI mode.

[Disabled] Disable the CSM to fully support the non-UEFI driver add-on devices

or the Windows

UEFI mode.

The following items appear when you set the Launch CSM to [Enabled].

Boot Device Control [UEFI and L...]

Allows you to select the type of devices that you want to boot.

Conguration options: [UEFI and Legacy OPROM] [Legacy OPROM only]

[UEFI only]

Boot from Network Devices [Legacy OPR...]

Allows you to select the type of network devices that you want to launch.

Conguration options: [Legacy OPROM rst] [UEFI driver rst] [Ignore]

Boot from Storage Devices [Legacy OPR...]

Allows you to select the type of storage devices that you want to launch.

Conguration options: [Both, Legacy OPROM rst] [Both, UEFI rst]

[Legacy OPROM rst] [UEFI driver rst] [Ignore]

Boot from PCIe Expansion Devices [Legacy OPR...]

Allows you to select the type of PCIe/PCI expansion devices that you want to

launch.

Conguration options: [Legacy OPROM rst] [UEFI driver rst]
