2-7
ASUS TS700-E8-PS4, TS700-E8-RS8
10. Pushdowntherightloadlever(I)ensuringthattheedgeoftheloadplateisxedand
tuckedsecurelyunderthelever(J)theninsert the right load lever under the retention
tab(K).
The PnP cap pops out of the load plate when the right load lever is inserted into the
retentiontab.
KeepthePnPcap.ASUSwillprocessReturnMerchandiseAuthorization(RMA)requests
onlyifthemotherboardcomeswiththePnPcapontheLGA2011socket.
11. Pushdowntheleftloadlever(L)then
insertitundertheretentiontab(M).
PnP cap
Retention tab
