Chapter 2: Hardware setup
2-6
9. Gentlypushtheloadplatejustenough
to let it sit on top of the CPU.
Do not force to close the load plate
as it may damage the CPU.
4. Push the left load lever to slightly lift the
loadplate(G).
Do not insert the load lever into the
retentiontab.
TheCPUtsinonlyonecorrect
orientation. DO NOT force the CPU
intothesockettopreventbendingthe
CPU pins on the socket.
6. GettheCPU.
7. AlignandpositiontheCPUoverthe
socket ensuring that the triangle mark on
the CPU matches the triangle mark on
thesocketbox.
5. Holdtheedgethengentlylifttheload
plate(H).
8. InstalltheCPUintotheslot.
Edge of the
Load plate
Load plate
Triangle mark
