6
ENGLISH
Normal Wind:( when two indicators are off)
Constant rotation with different wind speed
of “LOW”, “MED” and “HI” as preset by the
“SPEED” (21) button.
Natural Wind:
The fan operates in a circle of Hi, Medium
and Low as preset by microcomputer pro-
gram. Wind speed changes from light to
strong.
Sleeping Mode:
Under this mode, the speed will lower down
gradually to accommodate the change of
human body temperature, eliminating the
risk of getting cold during sleeping. The
lowering procedure will be as follows:
(1) When set at “Hi” position at the begin-
ning, the fan will work at high speed for half
an hour, and then it will switch to medium
wind speed. After another half an hour, it
will change from medium wind speed to low
wind speed.
(2) When set at “Medium” position at the be-
ginning, the fan will work at medium speed
for half an hour, then the fan switch to low
speed.
(3) When set at “Low” position at the begin-
ning, the fan will operate at low speed.
Natural Mode: (when two indicators are on)
When both the two mode indicators light up
simultaneously, High, Medium, during an
hour.
(1) When set at high natural wind position,
the unit will operate from high to medium af-
ter one hour. The unit will stop at the preset
time or whenever it is ВЫКЛ..
(2) When set at medium natural wind posi-
tion. The unit will work at this position till the
unit stops at the preset time or whenever it
is ВЫКЛ..
• Press the “ВЫКЛ.” (23) button to switch the
unit to “STAND-BY”.
Timer setting
To switch on Timer, press the “ТАЙМЕР” (20)
button on the control panel, each press in-
creases timer operation by 1/2. Max. timer
operation time is 7,5 hours. Timer indictor will
light up on the indication panel (27). After the
set time passes the unit will switch ВЫКЛ..
Remote control usage:
Open the battery compartment lid of the re-
mote control (5) and put 2 batteries of “ААА”
type, strictly following the polarity. Close the
battery compartment lid
Attention:
Functions of the buttons on the remote con-
trol (5) fully correspond to those on the con-
trol pa-nel (1).
Ionization mode
Ionization is performed in continuous mode;
indicator (33) shows it. Negatively charged
ions generator enriches air with millions of
negatively charged ions, useful for health.
Usage of “ICE BOX” (38)
The unit is equipped with two unique “ice box-
es” (38), preserving cool, they can decrease
water temperature in water tank, thus the wind
will be cooler.
Operation Method
1) Put the ICE BOXES into the refrigerator and
keep them inside till they are completely
frozen.
2) Put them into the water tank from the water
tank cover (18) on the left of the unit. And
then close the unit. The temperature of the
water will be lower than that of the ambi-
ence, making the wind cooler.
3) The unit assembles with two ICE BOXES,
which should be periodically frozen.
Troubleshooting
Problem Causes Solution
The unit
can not be
switched
on
1. The unit is
not con-
nected to
the wall
outlet.
2. Absence of
voltage in
the outlet.
3. Malfunc-
tion of the
unit.
1. Connect the
unit to the wall
outlet.
2. Try to connect
another ap-
pliance to the
same outlet.
3. Apply to the au-
thorized service
center for repair
of the unit.
2170.indd 62170.indd 6 24.06.2008 9:52:4324.06.2008 9:52:43
