MPC-2150 Hardware Display Control Interface Commands
B-5
SWK (Touch Keypad Firmware Version Query)
This command is to query the touch keypad firmware version.
Example:
Query Touch Keypad Firmware Version
0x07 0xFF 0x53 0x57 0x4B 0x00 0x04
ADF (AC Input Power Detect Function)
This default value of this function is OFF. If the MPC-2150 supports AC power input, users can turn on this
function to detect AC input power when the MPC-2150 has connected to the AC power. LEN=one date byte.
0x00 AC Input Power Detect is OFF
0xFF AC Input Power Detect is ON
Example:
Set “OFF”.
0x07 0xFF 0x41 0x44 0x46 0x01 0x2D 0x00 0xFF
ACK
0x06 0xFF 0x41 0x44 0x46 0x01 0x2E 0x00 0xFF
AD? (Query AC Input Power Detect Function Status)
If the MPC-2150 supports AC power input, users can use command is to query AC Input Power Detect Function
Status.
0x00 AC Input Power Detect is OFF
0xFF AC Input Power Detect is ON
Example:
Send AD? command to Query AC Input Power Detect Function Status
0x07 0xFF 0x41 0x44 0x3F 0x00 0x35
ACK
0x06 0xFF 0x41 0x44 0x3F 0x01 0x35 0x00 0xFF
BLI (Brightness Control)
This command is to set the panel brightness. Brightness range is from 0x00 to 0xFF. Default Brightness is 160.
LEN=one date byte.
Example:
Set brightness to 255(0xFF)
0x07 0xFF 0x42 0x4C 0x49 0x01 0x21 0xFF 0x00
ACK
0x06 0xFF 0x42 0x4C 0x49 0x01 0x22 0xFF 0x00
Query current brightness value
0x07 0xFF 0x42 0x4C 0x49 0x00 0x22
ACK
0x06 0xFF 0x42 0x4C 0x49 0x01 0x22 0xFF 0x00
