MPC-2150 Hardware Display Control Interface Commands
B-6
DUF (Disable UART Command Function)
Users can use this command to disable related command control. LEN=one date byte.
DATA IDCHK Function description
0x00 0xFF Disable all command control
0x01 0xFE Disable BRI control
0x02 0xFD Disable BRL control
0x04 0xFB Disable BRM control
0x08 0xF7 Disable BZZ control
0x10 0xEF Disable ETC control
0x20 0xDF Disable GMB control
0x40 0xBF Disable POT control
Example:
Disable all command control
0x07 0xFF 0x44 0x55 0x46 0x01 0x19 0x00 0xFF
ACK
0x06 0xFF 0x44 0x55 0x46 0x01 0x1A 0x00 0xFF
NACK
0x15 0xFF 0x44 0x55 0x46 0x01 0x0B 0x00 0xFF
EMS (ECDIS Mode Select)
For the ECDIS models, users can use this command to switch DAY, DUSK and NIGHT mode. LEN=one date
byte.
DATA IDCHK
DAY 0x00 0xFF
DUSK 0x01 0xFE
NIGHT 0x02 0xFD
Example:
Switch to DUSK mode
0x07 0xFF 0x45 0x4D 0x53 0x01 0x13 0x01 0xFE
ACK
0x06 0xFF 0x45 0x4D 0x53 0x01 0x14 0x01 0xFE
NACK
0x15 0xFF 0x45 0x4D 0x53 0x01 0x0B 0x01 0xFE
