Telwin tecnica 164 230v acx+maschera [12/60] Installation

that the welding machine can supply during welding

Wait until the LED (Fig.C(3)) has gone out completely

- X : Duty cycle: indicates the time for which the welding

before switching on again.

machine can supply the corresponding current (same

column). It is expressed as %, based on a 10 minutes

CONTROL, REGULATION AND CONNECTION

cycle (e.g. 60% = 6 minutes working, 4 minutes pause,

DEVICES

and so on).

WELDING MACHINE

If the usage factors (on the plate, referring to a 40°C

Front Panel

environment) are exceeded, the thermal safeguard

Fig. C

will trigger (the welding machine will remain in stand-

1 - Positive quick plug (+) to connect welding cable.

by until its temperature returns within the allowed

2 - YELLOW LED: normally off, when ON it means that the

limits).

welding current cannot flow due to one of the following

- A/V-A/V: shows the range of adjustment for the welding

faults:

current (minimum-maximum) at the corresponding

- Thermal protection: inside the machine the

arc voltage.

temperature is excessive. The machine is ON but does

9- Technical specifications for power supply line:

not deliver current until a normal temperature is

- U : Alternating voltage and power supply frequency of

reached. Once this happens the re-start is automatic.

welding machine (allowed limit ±10%):

- Mains over/undervoltage protection: when mains

- I : Maximum current absorbed by the line.

voltage is either too high or too low the machine is

1 max

blocked.

- I : : effective current supplied.

1eff

- ANTI STICK protection: automatically shuts down

10- : Size of delayed action fuses to be used to

the welding machine if the electrode sticks to the

protect the power line.

material being welded so that it can be removed

11- Symbols referring to safety regulations, whose meaning

manually without damaging the electrode holder

is given in chapter 1 “General safety considerations for

clamp.

arc welding”.

3- GREEN LED : Connection to the mains, machine ready

to work.

Note: The data plate shown above is an example to give the

4 - Potentiometer to regulate welding current with

meaning of the symbols and numbers; the exact values of

graduated scale in Amps, which also allows regulation

technical data for the welding machine in your possession

during welding.

must be checked directly on the data plate of the welding

(The “DUAL VOLTAGE AUTOMATIC” model has a

machine itself.

double graduated Ampere scale).

5 - Negative quick plug (-) to connect welding cable.

OTHER TECHNICAL DATA

- WELDING MACHINE: see table 1 (TAB.1)

Back panel

- ELECTRODE HOLDER CLAMP: see table 2 (TAB.2)

Fig. D

The welding machine weight is shown in table 1 (TAB. 1)

1 - Mains cable with E.E.C. 2p plug + (W).

(For the “DUAL VOLTAGE AUTOMATIC” model the cable

has no plug).

4. DESCRIPTION OF THE WELDING

2 - General luminous switch O/OFF - I/ON.

MACHINE

The unit is comprised of power modules which have been

developed on a specially printed circuit designed to

5. INSTALLATION

________________________________________________________________________________

maximise reliability and reduce maintainance.

Fig. B

WARNING! CARRY OUT ALL INSTALLATION

1 - Mains input (single phase), rectifier unit and condenser.

OPERATIONS AND ELECTRICAL CONNECTIONS WITH

2 - Transistors and drivers switching bridge (IGBT).

THE WELDING MACHINE COMPLETELY SWITCHED

It turns the mains rectified voltage into high frequency

OFF AND DISCONNECTED FROM THE POWER SUPPLY

alternate voltage and permits power regulation

OUTLET.

according to the current/voltage of the weld to be done.

THE ELECTRICAL CONNECTIONS MUST BE MADE

3 - High frequency transformer: the primary windings are

ONLY AND EXCLUSIVELY BY AUTHORISED OR

fed by the voltage converted by Block 2, it has the

function of adapting voltage and current to the values

QUALIFIED PERSONNEL.

________________________________________________________________________________

required by the arc welding procedure and,

simultaneously, isolates the welding circuit from the

PREPARATION

mains.

Unpack the welding machine, assemble the separate parts

4 - Secondary rectifier bridge with inductance: this

contained in the package.

changes the alternate voltage/current supplied by the

secondary windings into continuous current/voltage at a

Assembling the return cable-clamp

low wave-length.

Fig. E

5 - Electronic and regulation board: this instantly checks

the value of the welding current against that selected by

Assembling the welding cable-electrode holder clamp

the user, it modulates the commands of the IGBT

Fig. F

drivers, which control Regulation. Determines the

dynamic response of the current while the electrode

POSITION OF THE WELDING MACHINE

melts (instantaneous short circuits), and supervises the

Choose the place to install the welding machine so that the

safety systems.

cooling air inlets and outlets are not obstructed (forced

circulation by fan, if present); at the same time make sure

The "DUAL VOLTAGE AUTOMATIC" model has a device

that conductive dusts, corrosive vapours, humidity etc. will

that automatically recognises the power supply voltage

not be sucked into the machine.

(115V AC- 230V AC) and sets up the machine for correct

Leave at least 250mm free space around the welding

operation.

machine.

The user will be able to understand whether the machine

______________________________________________

power supply is 115V AC or 230V AC from the colour of the

LED (Fig C (3)).

WARNING! Position the welding machine on a flat

- GREEN LED shows that the machine is connected to a

surface with sufficient carrying capacity for its weight,

230V AC power supply.

to prevent it from tipping or moving hazardously.

- ORANGE LED shows that the machine is connected to a

______________________________________________

115V AC power supply.

During operation at 115V AC it is possible that

prolonged and sizeable voltage surges will cause the

CONNECTION TO THE MAIN POWER SUPPLY

machine to switch to 230V AC operation for safety.

- Before making any electrical connection, make sure the

In such circumstances, to resume welding, the

rating data of the welding machine correspond to the

machine must be switched off and on again.

- 12 -
