FG080 –EPSILON 07-12 RAC
10
5.0 INSTALLATION
1 Ensure that the depositor is connected to the correct electric supply as specified on
the serial number plate on the side of the machine.
2 Ensure that the correct fuse rating is fitted in the electrical supply.
3 The support table should be level and strong enough to support the machine and
loaded hopper.
4 This machine should be lifted by more than one person.
6.0 ISOLATION
IN AN EMERGENCY, SWITCH OFF AT THE MAINS
WALL ISOLATOR, OR PUSH EMERGENCY
STOP BUTTON.
To release the emergency stop button, turn clockwise.
STOP BUTTON
EPSILON
