FG080 –EPSILON 07-12 RAC
24
OPERATOR SCREEN
PRIME PUMP
USE THIS TO GET A
CONSISTANT FLOW
OF MIX.
WEIGHT VALUE
ADJUSTMENT
WEIGHT VALUE
PROGRAM NAME
3
THIS SCREEN CONTROLS THE ACTIONS REQUIRED BY THE OPERATOR.
RETURN
TO PREVIOUS SCREEN
START
STOP
PART
