FG080 –EPSILON 07-12 RAC
26
EXAMPLE:
TOWER
NOZZLE HEIGHT
(mm)
FOR EACH LAYER
NOZZLE HEIGHT
(mm)
FROM TRAY SURFACE
DEPOSIT QUANTITY
FOR EACH LAYER
0
OTHER SETTING BUTTONS ARE THE
SAME AS THE PREVIOUS PAGE
EXAMPLE:
STRIP
DEPOSIT QUA
NTITY
FOR BEGINNING OF
PRODUCT
DEPOSIT QUANTITY
FOR LENGTH
DEPOSIT QUANTITY
FOR END OF
PRODUCT
(-VE VALUES POSSIBLE)
NOZZLE HEIGHT
ABOVE TRAY
SURFACE
LENGTH
(mm) OF
DEPOSIT
OTHER SETTING BUTTONS ARE THE
SAME AS THE PREVIOUS PAGE
