FG080 –EPSILON 07-12 RAC
27
EXAMPLE:
SHEETING
DEPOSIT QUANTITY
FOR BEGINNING OF
PRODUCT
DEPOSIT QUANTITY
FOR LENGTH
DEPOSIT QUANTITY
FOR END OF
PRODUCT
(-VE VALUES POSSIBLE)
NOZZLE HEIGHT
ABOVE TRAY
SURFACE
LENGTH
(mm) OF
DEPOSIT
OTHER SETTING BUTTONS ARE THE
SAME AS THE PREVIOUS PAGE
