FG080 –EPSILON 07-12 RAC
21
=
KEYBOARD ENTRY
REQUIRED
BLUE
=
OPERATION
RED
=
CHANGE SETTINGS
OPERATING KEY
FOR FOLLOWING INSTRUCTIONS
FOLLOW BLUE ARROWS AND BOXES TO
OPERATE THE DEPOSITOR WITH ALREADY
SAVED PROGRAMS
FOLLOW RED ARROWS AND BOXES TO
CHANGE SETTINGS AND CREATE NEW
PROGRAMS
WHEN KEYBOARD APPEARS, A CODE
MUST BE ENTERED BY TOUCHING THE
NUMBERS IN THE CORRECT ORDER
IF A GREY BOX IS SHOWN IN THE BUTTON DESCRIPTION
e.g. GO TO THE CORRESPONDING PAGE FURTHER
ON IN THE INSTRUCTIONS.
(MARKED IN TOP RIGHT HAND CORNER OF EACH PAGE)
7
