25
Ɣ Move the guide bar (20) away from the driving chain wheel, so chain guiding links are placed in the
guide bar groove.
Ɣ Ensure the pin (a) of the chain tension adjustment screw (8) is in the middle of the lower hole (b) of the
guide bar (20), adjust when necessary (g. B).
Ɣ Place the casing (10) in its place and fix by slightly tightening guide bar fixing nuts (7) (27).
Ɣ Strain the chain appropriately using the chain tension adjustment screw (8). Chain tension is appropriate
when the chain can be lifted by 3 to 4 mm in the middle of the guide bar in horizontal position.
Ɣ Firmly tighten guide bar fixing screws (7) (27) while holding the guide bar tip.
Prior to guide bar and chain installation ensure that position of chain cutting blades is appropriate
(correct position of the chain on the guide bar is shown on the tip of the guide bar). Always wear
protective gloves during checks and installation of the chain to prevent cuts from sharp edges of
the chain.
New chain requires start-up period, which lasts approximately 5 minutes. Chain lubrication is very
important in this phase. Check chain tension after start-up period and readjust if necessary.
Check and adjust the chain tension frequently. Too loose chain can easily slide o the guide bar,
quickly wear out or quickly wear out the guide bar.
FILLING SAW TANK WITH OIL
Oil tank in new chain saw is empty. Fill the tank with oil prior to first use.
Ɣ Unscrew oil filler plug (18).
Ɣ Pour in maximally 160 ml of oil (be careful to avoid contamination of oil during filling of the tank).
Ɣ Screw oil filler plug (18).
Do not use oil that has been already used or regenerated, as this may damage the oil pump.
Use SAE
10W/30 oil for the whole year, or SAE 30W/40 in summer and SAE 20W/30 in winter.
FILLING THE FUEL TANK
When lling the fuel, follow these rules:
Ɣ engine must not work,
Ɣ you must not spill the fuel.
Accordingly to the below table, mix petrol (lead-free with octane number 95) with good quality engine oil
for two stroke engines.
Table for 25 : 1 fuel blend
Petrol (litres) 1 2 3 4 5
Oil for 2-stroke engines (ml) 40 80 120 160 200
Ɣ Pour appropriate amount of oil into a canister, and add exactly measured amount of petrol.
Ɣ Screw the cap and mix thoroughly.
Ɣ Unscrew fuel filler plug (15).
Ɣ Pour in previously prepared fuel blend (max. 230 ml).
Ɣ Screw fuel filler plug (15).
Most problems with combustion engines result directly or indirectly from fuel used. You must not
use oil designed for four-stroke engines to prepare fuel blend.
INSTALLATION AND ADJUSTMENT OF SHOULDER STRAP
Switch o the engine before installation and adjustment of the shoulder strap and shoulder strap
holder.
Appropriate adjustment of the shoulder strap facilitates using the device.
Ɣ Put the shoulder strap (23) over your head and shoulder (g. Q).
Ɣ Put the shoulder strap spring hook (24) (g. V) in the shoulder strap holder (25).
Ɣ Use the shoulder strap fastener (23) (g. Q) to adjust shoulder strap length to set the most comfortable
working position.
