Trotec ProMarker 300 [18/43] Technical data
![Trotec ProMarker 300 [18/43] Technical data](/views2/1404789/page18/bg12.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 18 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
6 Technical Data
6.1 General Description
All electronic components are integrated in the machine. All necessary
connectors are located on the reverse side of the laser rack.
6.2 Laser Rack Dimensions
