Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 41 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
12 Troubleshooting
This chapter should assist maintenance personnel with the
identification and resolution of operational faults based on error
messages and symptoms.
Maintenance and repair work should only be carried out by
Trotec Produktions und Vertriebs Ges.m.b.H. or one of its
authorised personnel under observation of the safety regulations.
12.1 Problem Resolution
Problem Possible cause Resolution
Error message on
loading the program
Plug or cable installed
incorrectly
Check the plug and cable are installed
correctly
Laser power supply switched off Turn on main switch
Software not installed correctly Re-install software
Software terminated irregularly Restart PC
Laser
will not switch on
Plug or cable installed
incorrectly
Check the plug and cable are installed
correctly
Laser power supply switched off Turn on main switch
Faulty fuse in laser power supply
Replace fuse
Status lamps on marking
head remain green
Interlock circuit not closed
Check interlock circuit
If no interlock circuit is connected, use
bridging connector X11.
No laser beam Laser not in focus Check working distance
Shutter closed
Open shutter - if not possible
check interlock circuit
Incorrect laser parameters
Check the parameters in the program.
Use suitable parameters for the
material and application
Insufficient laser output
Laser not in focus Check working distance
Incorrect laser parameters
Check the parameters in the program.
Use suitable parameters for the
material and application
Missing symbols Focusing lens dirty Clean focusing lens
Surface of the material dirty Clean material surface
Other faults Contact TROTEC Support
