8.5 Emission Indicator
The laser system is fitted with an emission indicator. If the system is
switched on or the safety lock is open, there is usually a possibility that
laser radiation will be emitted. This is signalled by a separate indicator
and/or an illuminated “Shutter” switch.
The emission lamps or illuminated shutter switch signal that:
Emission indicator off – device without power
Emission indicator yellow – shutter closed, no laser output
Emission indicator red – shutter open, discharge of laser output
possible
