Trotec ProMarker 300 [31/43] Switching on off
![Trotec ProMarker 100 [31/43] Switching on off](/views2/1404789/page31/bg1f.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 31 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
8.4 Switching On/Off
1. Press the master switch on the laser rack.
2. The switch is illuminated in green and the two status lamps on the
marking head also illuminate in green (shutter closed).
3. Put the key in the key switch (vertically) and turn 90° to the
right.
4. Press the “Error reset” button to reset the system to its normal
state.
5. System ready , Shutter and the two status lamps (red) on
the marking head should now be illuminated. The laser is now
ready to start marking.
6. Start the PC. (The mains switch is located on the front behind the
right hand cover. When operating the system for the first time it
may be necessary to check the master switch on the reverse side
of the PC. In its normal state this can remain in the “On” position.)
7. Now start the marking software on the PC
If an error occurs, the “Error Reset” button illuminates. Pressing
this button acknowledges the error and the system is then ready to
continue operating.
We recommending using only the key switch to pause the laser.
To completely turn off the laser, the main switch must be set to O.
7
6
1
1
7
2
3
6
