3.2 Intended Use
The Promarker is a Class 4 laser marker as per DIN EN 60825-1
“Safety of laser products”. It is intended for integration in systems and
lines.
The Promarker is intended exclusively for laser marking using the
supplied marking software.
The following points should also be observed as part of the intended
use:
- only mark approved materials using suitable parameters
- perform maintenance and service according to the
specifications in this operation manual
- use a suitable extraction system to remove fumes, dust or
other reaction products
- the machine may only be operated by suitably trained
individuals
- observe effective safety regulations and the procedures
described in this operation manual
If the intention is to use the system for other applications, Trotec
Produktions und Vertriebs Ges.m.b.H. should be informed in advance.
