Trotec ProMarker 300 [39/43] Replacing the filter pad
![Trotec ProMarker 300 [39/43] Replacing the filter pad](/views2/1404789/page39/bg27.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 39 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
10.3 Replacing the Filter Pad
This laser system is fitted with a ventilation system. A filter pad is used
to protect the electronic components from dust and dirt in the ambient
air.
This filter pad should be checked and replaced at regular intervals in
order to ensure optimum cooling.
The filter pad is located behind the ventilation slots on the front of the
laser rack.
Laser rack filter pad:
•
Filter pad cover
