Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 38 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
Small bellows should be used to remove dust.
Do not use compressed air as it contains small quantities of oil
and water.
To remove larger pieces of dirt, only use a lens cleaning cloth with
high proof (min. 98 %) alcohol.
Do not dip the cleaning cloth in the cleaning solution. This
contaminates the solution and makes it unusable. Place drops of
the solution on the cloth!
Apply the cleaning solution carefully in order to avoid scratching
the surface of the lens.
Do not wipe the lens with a dry cloth. Do not touch the reverse
side of the cloth. Dirt and sebum on the fingers can be
transferred to the lens by the cloth and cause damage.
Distribute the cleaning fluid carefully using small circular motions. Start
at the centre of the lens and move outwards to the edge. Keep moving
the cloth until the entire surface is clean.
Do not exert any pressure on the lens.
