Trotec ProMarker 300 [42/43] Possible error messages
![Trotec ProMarker 300 [42/43] Possible error messages](/views2/1404789/page42/bg2a.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 42 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
12.2 Possible Error Messages
Below is a list of possible errors which may be detected by the system.
These will appear in the software as messages on the display.
The Reset signal (X11) or the reset button on the laser rack are used
to acknowledge an error. In order for the system to be reset, the error
or the corresponding input signal must be acknowledged.
System errors which cannot be reset or which indicate a
hardware error should only be resolved by Trotec Produktions
und Vertriebs Ges.m.b.H. trained service personnel.
Error message Cause
Card off line
Software has lost connection to the TLC2
controller
Scanner not connected
No connection to the galvo
Scanner X error
The galvo X-axis has identified an error
Scanner Y error
The galvo Y-axis has identified an error
Signal cable not connected
No connection to the marking head
External abort
External abort signal identified on X11
External stop
External stop signal identified on X11
Voltage error (15V)
+/- 15V power supply not functioning correctly
Voltage error (24V)
24V power supply not functioning correctly
Laser power supply error
Faulty laser source power supply
Shutter error
Shutter has not reached intended position
Cover connector opened during marking
ICL1 and ICL2 were opened during the
marking process
External sum alarm
External error signal identified on X11
System locked by key switch
Key switch on laser rack locked
Laser temperature
Laser source overheated
Laser power
24 V power supply outside the permissible
tolerance zone
Laser not ready for emission
e.g. key switch not activated
Laser back reflection
Back reflection of the laser beam
Laser system error
Laser power supply voltage is too high or too
low
Emergency stop button
Emergency stop button activated
Error
+/-15V monitoring
24V laser monitoring
24V monitoring
Shutter temperature
Required shutter position
