Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 30 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
8.3 Operating Controls
Main switch
System ready – control lamp
Shutter – control lamp
Laser busy – control lamp
Emergency stop – button
Error reset – button
Key switch
3
1
2
4
5
6
7
3
1
2
4
5
6
7
