Trotec ProMarker 300 [40/43] Transportation and storage
![Trotec ProMarker 100 [40/43] Transportation and storage](/views2/1404789/page40/bg28.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 40 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
11 Transportation and Storage
11.1 Transportation Conditions
•
When transporting outside, always transport in a covered vehicle
or one with sufficient weather-proofing.
•
Protect the machine against transportation damage using straps
and inserts, and leave sufficient distance between other
transported items.
•
Ambient temperature for transportation:
Min. temp. 10 °C
Max. temp. 40 °C
•
Handle the machine and machine components with care.
•
Do not place any heavy loads on the machine or machine
components.
•
Avoid heavy impacts.
•
Take particular care when transporting electronic components.
11.2 Storage Conditions
•
Store the machine and machine components in a dry location.
•
Protect the machine and machine components against scratches.
•
Take particular care when packing away electronic components.
•
When storing for a long period of time, preserve bare metal parts
(e.g. apply oil).
•
Ambient temperature for storage:
Min. temp. 10 °C
Max. temp. 40 °C
11.3 Storage Location
Storage room or boxed with sufficient weather-proofing. The storage
location must be free from corrosive elements, fumes and flammable
materials.
