Trotec ProMarker 300 [20/43] Data sheet
![Trotec ProMarker 300 [20/43] Data sheet](/views2/1404789/page20/bg14.png)
Promarker
Operation Manual
09/01/2012 Trotec Produktions- und Vertriebs GmbH_Linzer Strasse 156, A-4600 Wels, Austria, Technical Support 20 / 43
tel_+43 (0)7242 239-7000, fax_+43 (0)7242 239-7380, e-mail: techsupport@troteclaser.com
6.4 Data Sheet
Laser
Laser Pulsed Yb fibre laser, maintenance free
Laser output 10 and 20 Watt, depending on model
Wave length 1064 nm ± 8
Pulse length 110ns
Ventilation Air-cooled
Galvo Scanner
F-100
Standard:
F-160
F-254
Work areas
70 x 70 mm 110 x 110 mm 180 x 180 mm
Focus diameter ~27 µm ~45 µm ~68 µm
Positioning Speed 10 m/s for F=160 mm
Marking Speed 640cps per 1 mm single stroke
Operating distance ~134,6mm ~211,6mm ~361,6mm
Control
PC requirements Windows XP (SP2) or Windows 7 (32bit)
CD drive, 256 MB RAM, 200MB disc space, 1GHz Processor,
24bit graphic card, resolution 1024 x 768
One free PCI slot + 3 free Slots on the PC
Application software DirectMark
Dimensions
Dimensions Marking head : 120 x 138 x 528 (W/H/D)
Laser rack: 448,9 x 140 x 686 (W/H/D)
Weight Marking head: approx. 8 kg
Assembly
Environmental conditions Ambient temperature +15 to +35° C.
Relative air humidity max. 90 %.
No condensation
Power supply
1/N/PE AC
100 - 240 V 50/60 Hz
Power consumption < 100 W
Optional Extras
Extended warranty
Various Class 2 laser work stations
Focus finder
Motorized Z-axis
Laser Safety
Laser class CDRH laser safety
Laser Class 4
CE tested
