X71 – Start / Stop
The X71 connector may be used to send start and stop signals via
an external controller or receive a signal from the laser. The pin
configuration is provided in 7.3.5
“Busy” is a laser output which can be set as required using a
script.
“Stop” is an external input used to interrupt all running laser
programs immediately. It is not necessary to monitor these inputs
in a script.
“Start” is an external input which may be monitored in the software
in order to trigger a marking process. If the monitoring of the signal
is not active within a script, the input will have no effect on the
program sequence.
For the “Start” and “Stop” Signal external 24VDC are needed.
If no external emergency stop circuit is connected, the supplied
connector must be used with the bridging devices. In this case,
only the emergency stop button on the front of the laser rack is
active. The precise pin configuration of the plug is provided in 7.3.5
The maximum load of each of the digital 24V outputs on the
interface is 100mA. A short circuit of the outputs must be avoided
as it will damage the respective inputs.
