Installation & Maintenance : 6564868 08/2008
13
Dimensional Data
HIGH EFFICIENCY - STANDARD UNITS
A B C D E F G1 G2 H J K L (10)
OPC500HED8 mm 2600 2200 4675 460 1056 2412 1250 N/A 1250 N/A N/A 425 DN150 PN16
OPC525HED8 mm 2600 2200 4675 460 1056 2412 1250 N/A 1250 N/A N/A 425 DN150 PN16
OPC550HED8 mm 2600 2200 4675 460 1056 2412 1250 N/A 1250 N/A N/A 425 DN150 PN16
OPC600HED10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC650HED10 mm 2600 2200 5675 510 1582 2360 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC700HED12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC750HED12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC800HED12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC850HED12 mm 2600 2200 7100 510 2304 3210 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC900HED14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC950HED14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC1000HED16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC1100HED16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
A B C D E F G1 G2 H J K L (10)
OPC500HEDQ10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC525HEDQ10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC550HEDQ10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC600HEDQ10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC650HEDQ10 mm 2600 2200 5675 460 1556 2412 1750 N/A 1250 N/A N/A 425 DN150 PN16
OPC700HEDQ14 mm 2600 2200 8100 510 2730 2360 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC750HEDQ14 mm 2600 2200 8100 510 2730 2360 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC800HEDQ14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC850HEDQ14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC900HEDQ16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC950HEDQ16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC1000HEDQ18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
OPC1100HEDQ18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
HIGH EFFICIENCY PLUS - STANDARD UNITS
A B C D E F G1 G2 H J K L (10)
OPC500HE+D8 mm 2600 2200 4675 510 1082 2360 1250 N/A 1250 N/A N/A 425 DN200 PN16
OPC525HE+D10 mm 2600 2200 5675 510 1582 2360 1750 N/A 1250 N/A N/A 425 DN200 PN16
OPC550HE+D10 mm 2600 2200 5675 510 1582 2360 1750 N/A 1250 N/A N/A 425 DN200 PN16
OPC600HE+D10 mm 2600 2200 5675 510 1582 2360 1750 N/A 1250 N/A N/A 425 DN200 PN16
OPC650HE+D10 mm 2600 2200 5675 510 1157 3210 1750 N/A 1250 N/A N/A 425 DN200 PN16
OPC700HE+D12 mm 2600 2200 7100 510 2304 3210 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC750HE+D12 mm 2600 2200 7100 510 2304 3210 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC800HE+D14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC850HE+D14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC900HE+D16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC950HE+D18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
OPC1000HE+D18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
OPC1100HE+D18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
A B C D E F G1 G2 H J K L (10)
OPC500HE+DQ12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC525HE+DQ12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC550HE+DQ12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC600HE+DQ12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC650HE+DQ12 mm 2600 2200 7100 510 2730 2360 1850 N/A 1200 1175 1775 600 DN200 PN16
OPC700HE+DQ14 mm 2600 2200 8100 510 2304 3210 2000 N/A 1400 1400 2000 800 DN200 PN16
OPC750HE+DQ16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC800HE+DQ16 mm 2600 2200 9100 510 3304 3210 2875 N/A 1400 1400 2325 600 DN200 PN16
OPC850HE+DQ18 mm 2600 2200 10100 510 3304 3210 3000 N/A 1400 1400 3000 800 DN200 PN16
OPC900HE+DQ20 mm 2600 2200 11100 510 4304 3210 2000 2000 1400 1400 2700 1100 DN200 PN16
OPC950HE+DQ20 mm 2600 2200 11100 510 4304 3210 2000 2000 1400 1400 2700 1100 DN200 PN16
OPC1000HE+DQ20 mm 2600 2200 11100 510 4304 3210 2000 2000 1400 1400 2700 1100 DN200 PN16
OPC1100HE+DQ20 mm 2600 2200 11100 510 4304 3210 2000 2000 1400 1400 2700 1100 DN200 PN16
(1) Mains Electric Isolator(s), for unit isolation refer to (6).
(2) Emergency Stop.
(3) Mains Electric Panel(s), for unit isolation refer to (6).
(4) Microprocessor Control Panel.
(5) Compressor Enclosure (DQ Models Only).
(6) Mains Cable Entry to Busbar, unit incoming mains isolation supplied by others.
(7) Busbar Chamber.
(8) Lifting Lugs (removable).
8 - 10 Fan Unit x 8
12 - 18 Fan Unit x 10
(9) 20mm Ø Mounting Holes:
20 Fan Unit x 12
(10) Water Connections.
