Airedale OptiChill OPC 500 [46/60] Optichill chillers
![Airedale OptiChill OPC 500 [46/60] Optichill chillers](/views2/1409430/page46/bg2e.png)
OPTICHILL Chillers
Chillers
46
Installation & Maintenance : 6564868 08/2008
Commissioning Data
WATERSIDE PRESSURE DROP (KPA)
CAUTION
Full design water flow MUST be maintained at all times. Variable water volume is
NOT recommended and will invalidate warranty.
140
120
100
80
60
40
Waterside Pressure Drop (kPa)
20
1
4
3
2
0
15
20
25
30
35
40
45
50
55
60
65
70
Waterflow (l/s)
HED HEDQ HE+D HE+DQ
OPC500 112 2
OPC525 1 1 2 2
OPC550 112 2
OPC600 1 1 2 2
OPC650 213 2
OPC700 2 2 3 3
OPC750 224 3
OPC800 2 3 3 3
OPC850 333 3
OPC900 3 3 3 3
OPC950 333 3
OPC1000 3 3 3 3
OPC1100 333 3
(1) Chiller pressure drop refers to standard unit only. For pump options, please contact Airedale.
(2) For glycol solutions, please refer to
Glycol data, on page 26.
