OPTICHILL Chillers
Chillers
28
Installation & Maintenance : 6564868 08/2008
Installation Data
MECHANICAL DATA - HIGH EFFICIENCY
OPC500HED8 OPC525HED8 OPC550HED8 OPC600HED10 OPC650HED10
Connections Grooved type Coupling & Pipe Assembly
Water Inlet / Outlet DN150 PN16 DN150 PN16 DN150 PN16 DN150 PN16 DN200 PN16
Water Drain / Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume l 1764 1849 1934 2079 2260
Max. System Operating Pressure bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump - ac Motor (1) In Line Pump - Fixed Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 70 66 63 56 76
Nom External Head Single - Larger kPa 107 104 100 94 179
Water Pump - Inverter Driven Motor In Line Pump - Variable Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 124 120 117 67 87
Nom External Head Single - Larger kPa 124 120 117 155 174
OPC500HEDQ10 OPC525HEDQ10 OPC550HEDQ10 OPC600HEDQ10 OPC650HEDQ10
Connections Grooved type Coupling & Pipe Assembly
Water Inlet / Outlet DN150 PN16 DN150 PN16 DN150 PN16 DN150 PN16 DN150 PN16
Water Drain / Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume l 1750 1832 1915 2001 2087
Max. System Operating Pressure bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump - ac Motor (1) In Line Pump - Fixed Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 71 67 64 60 56
Nom External Head Single - Larger kPa 108 105 101 97 159
Water Pump - Inverter Driven Motor In Line Pump - Variable Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 124 121 118 71 67
Nom External Head Single - Larger kPa 124 121 118 159 155
MECHANICAL DATA - HIGH EFFICIENCY PLUS
OPC500HE+D8 OPC525HE+D10 OPC550HE+D10 OPC600HE+D10 OPC650HE+D10
Connections Grooved type Coupling & Pipe Assembly
Water Inlet / Outlet DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
Water Drain / Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume l 1825 1967 2067 2164 2297
Max. System Operating Pressure bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump - ac Motor (1) In Line Pump - Fixed Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 87 83 81 78 89
Nom External Head Single - Larger kPa 124 121 118 116 192
Water Pump - Inverter Driven Motor In Line Pump - Variable Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 140 137 135 89 100
Nom External Head Single - Larger kPa 140 137 135 177 187
OPC500HE+DQ12 OPC525HE+DQ12 OPC550HE+DQ12 OPC600HE+DQ12 OPC650HE+DQ12
Connections Grooved type Coupling & Pipe Assembly
Water Inlet / Outlet DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
Water Drain / Bleed in 1/2 1/2 1/2 1/2 1/2
Water System
Min. System Water Volume l 1850 1947 2044 2139 2234
Max. System Operating Pressure bar 10 10 10 10 10
OPTIONAL EXTRAS
Water Pump - ac Motor (1) In Line Pump - Fixed Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 86 84 81 79 76
Nom External Head Single - Larger kPa 123 121 119 116 179
Water Pump - Inverter Driven Motor In Line Pump - Variable Speed Motor
Single Head or Run/Standby
Nom External Head Single - Standard kPa 140 137 135 90 87
Nom External Head Single - Larger kPa 140 137 135 177 175
(1) Based on 12/7°C water temperature and 35°C ambient.
