Chillers OPTICHILL
Chillers
Installation & Maintenance : 6564868 08/2008
29
OPC700HED12 OPC750HED12 OPC800HED12 OPC850HED12 OPC900HED14 OPC950HED14 OPC1000HED16 OPC1100HED16
Grooved type Coupling & Pipe Assembly
DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
2475 2637 2779 2977 3171 3302 3518 3669
10 10 10 10 10 10 10 10
In Line Pump - Fixed Speed Motor
81 77 72 88 84 81 76 98
173 168 164 179 175 172 167 164
In Line Pump - Variable Speed Motor
81 76 71 87 111 108 103 99
168 163 159 174 170 167 226 222
OPC700HEDQ14 OPC750HEDQ14 OPC800HEDQ14 OPC850HEDQ14 OPC900HEDQ16 OPC950HEDQ16 OPC1000HEDQ18 OPC1100HEDQ18
Grooved type Coupling & Pipe Assembly
DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
2437 2594 2785 2928 3109 3231 3434 3581
10 10 10 10 10 10 10 10
In Line Pump - Fixed Speed Motor
82 78 92 89 85 83 78 100
174 169 183 180 177 174 169 166
In Line Pump - Variable Speed Motor
82 77 91 88 112 109 105 101
169 164 178 175 172 169 228 224
OPC700HE+D12 OPC750HE+D12 OPC800HE+D14 OPC850HE+D14 OPC900HE+D16 OPC950HE+D18 OPC1000HE+D18 OPC1100HE+D18
Grooved type Coupling & Pipe Assembly
DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
2519 2698 2891 3040 3226 3412 3567 3722
10 10 10 10 10 10 10 10
In Line Pump - Fixed Speed Motor
97 100 90 87 83 78 75 97
188 191 181 178 174 170 166 163
In Line Pump - Variable Speed Motor
96 99 89 86 109 105 102 98
184 187 176 173 169 165 224 221
OPC700HE+DQ14 OPC750HE+DQ16 OPC800HE+DQ16 OPC850HE+DQ18 OPC900HE+DQ20 OPC950HE+DQ20 OPC1000HE+DQ20 OPC1100HE+DQ20
Grooved type Coupling & Pipe Assembly
DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16 DN200 PN16
1/2 1/2 1/2 1/2 1/2 1/2 1/2 1/2
2480 2693 2840 3030 3201 3337 3486 3636
10 10 10 10 10 10 10 10
In Line Pump - Fixed Speed Motor
97 93 91 87 83 80 77 99
189 185 182 178 175 172 168 165
In Line Pump - Variable Speed Motor
97 93 90 86 110 107 104 100
184 180 177 173 170 167 226 223
