OPTICHILL Chillers
Chillers
36
Installation & Maintenance : 6564868 08/2008
Installation Data
IMPORTANT
The following information is for general guidance; refer to the certified drawings
provided for installation.
ELECTRICAL DATA - HIGH EFFICIENCY PLUS
Standard Chiller - D & Quiet Chiller - DQ
OPC500HE+D8 OPC525HE+D10 OPC550HE+D10 OPC600HE+D10 OPC650HE+D10
Unit Data
Nominal Run Amps (1) A 288 312 329 343 357
Maximum Start Amps (2) A 458 524 541 585 600
Rec Mains Fuse Size A 400 450 450 450 500
Mains Supply VAC 400 V 3 PH 50 Hz
Max Mains Incoming Cable Size mm² Direct to Bus Bar
Permanent Supply VAC 230 V 1 PH 50 Hz
Rec Permanent Fuse Size A 16 16 16 16 16
Max Permanent Incoming Cable Size mm² 4mm² Terminal
Control Circuit VAC 24V / 230VAC
Evaporator
Immersion Heater Rating W 100 100 100 100 100
External Trace Heating
Available (fitted by others) W 500 500 500 500 500
Condenser Fan - Per Fan
Quantity 8 10 10 10 10
Full Load Amps A 3.4 3.4 3.4 3.4 3.4
Motor Size kW 2.2 2.2 2.2 2.2 2.2
Compressor - Per Compressor
Quantity 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
Motor Size kW 74.5 / 74.5 83.4 / 74.5 83.4 / 83.4 91.8 / 83.4 91.8 / 91.8
Nominal Run Amps (1) A 130.4 / 130.4 147.3 / 130.4 147.3 / 147.3 161.5 / 147.3 161.5 / 161.5
Oil Heater Rating W 300 300 300 300 300
Start Amps (2) A 300 / 300 360 / 300 360 / 360 404 / 360 404 / 404
Type Of Start Star - Delta
QUIET DQ
OPC500HE+DQ12 OPC525HE+DQ12 OPC550HE+DQ12 OPC600HE+DQ12 OPC650HE+DQ12
All data as above except:
Condenser Fan - Per Fan
Quantity 12 12 12 12 12
Full Load Amps A 3.4 3.4 3.4 3.4 3.4
Motor Size kW 2.2 2.2 2.2 2.2 2.2
OPTIONAL EXTRAS - ALL MODELS
Power Factor Correction
Nominal Run Amps (1) A 254 274 287 300 313
Maximum Start Amps (2) A 440 507 521 565 577
Recommended Mains Fuse A 400 450 450 450 500
Compressor Nom Run Amps - Per
Compressor
A 113 / 113 127 / 113 127 / 127 139 / 127 139 / 139
Closed Transition
Nominal Run Amps (1) A 288 312 329 343 357
Maximum Start Amps (2) A 458 524 541 585 600
Recommended Mains Fuse A 400 450 450 450 500
Compressor Nom Run Amps - Per
Compressor
A 130.4 / 130.4 147.3 / 130.4 147.3 / 147.3 161.5 / 147.3 161.5 / 161.5
Water Pump - ac Motor
Single Head or Run/Standby - Standard
Unit Nominal Run Amps (1) A 297 321 337 352 366
Recommended Mains Fuse A 400 450 450 450 500
Motor Size kW 4.0 4.0 4.0 4.0 4.0
Full Load Amps A 8.9 8.9 8.9 8.9 10.6
Single Head or Run/Standby - Larger
Unit Nominal Run Amps (1) A 302 326 343 357 378
Recommended Mains Fuse A 400 450 450 500 500
Motor Size kW 7.5 7.5 7.5 7.5 11.0
Full Load Amps A 14.4 14.4 14.4 14.4 21.0
Water Pump - Inverter Driven Motor
Single Head or Run/Standby - Standard
Unit Nominal Run Amps (1) A 299 323 340 354 368
Recommended Mains Fuse A 400 450 450 450 500
Motor Size kW 5.5 5.5 5.5 5.5 5.5
Full Load Amps A 11.0 11.0 11.0 11.3 11.3
Single Head or Run/Standby - Larger
Unit Nominal Run Amps (1) A 299 323 340 358 372
Recommended Mains Fuse A 400 450 450 450 500
Motor Size kW 5.5 5.5 5.5 7.5 7.5
Full Load Amps A 11.0 11.0 11.0 15.0 15.0
(1) Based on 12/7°C water temperature and 35°C ambient.
(2) Starting amps refers to the Star connection only.
