Chillers OPTICHILL
Chillers
Installation & Maintenance : 6564868 08/2008
19
Installation Data
WEIGHTS - WITH OPTIONAL PUMPS (GUIDANCE)
CAUTION
Due to the number of different pump options available, the following table is
provided as a guide to the MAXIMUM weight of models with optional pumps fitted.
Once selection has been made, it is important to consult Airedale for the specific
details at time of enquiry to ensure lifting and support arrangements are sufficient.
Point Loadings and AV selection will be provided separately.
High Efficiency
OPC500HED8
OPC525HED8
OPC550HED8
OPC600HED10
OPC650HED10
OPC700HED12
OPC750HED12
OPC800HED12
OPC850HED12
OPC900HED14
OPC950HED14
OPC1000HED16
OPC1100HED16
Single Pump Option
Weight - Machine kg 5895 5915 5945 6435 6727 7697 8210 8220 8400 8943 9023 9550 9570
Weight - Operating kg 6135 6175 6185 6705 7147 8107 8610 8630 8940 9483 9573 10090 10090
Run/Standby Pump Option
Weight - Machine kg 6182 6202 6232 6722 7006 7976 8522 8532 8712 9250 9330 9874 9894
Weight - Operating kg 6422 6462 6472 6992 7426 8386 8922 8942 9252 9790 9880 10414 10414
OPC500HEDQ10
OPC525HEDQ10
OPC550HEDQ10
OPC600HEDQ10
OPC650HEDQ10
OPC700HEDQ14
OPC750HEDQ14
OPC800HEDQ14
OPC850HEDQ14
OPC900HEDQ16
OPC950HEDQ16
OPC1000HEDQ18
OPC1100HEDQ18
Single Pump Option
Weight - Machine kg 6795 6825 6845 6855 6907 8607 9110 9290 9300 9843 9933 10460 10480
Weight - Operating kg 7035 7065 7105 7105 7157 8997 9520 9820 9830 10363 10443 10990 11020
Run/Standby Pump Option
Weight - Machine kg 7082 7112 7132 7142 7186 8886 9422 9602 9612 10150 10240 10784 10804
Weight - Operating kg 7322 7352 7392 7392 7436 9276 9832 10132 10142 10670 10750 11314 11344
High Efficiency Plus
OPC500HE+D8
OPC525HE+D10
OPC550HE+D10
OPC600HE+D10
OPC650HE+D10
OPC700HE+D12
OPC750HE+D12
OPC800HE+D14
OPC850HE+D14
OPC900HE+D16
OPC950HE+D18
OPC1000HE+D18
OPC1100HE+D18
Single Pump Option
Weight - Machine kg 6125 6635 6665 6675 6887 7867 8390 8870 8880 9423 10003 10040 10060
Weight - Operating kg 6545 7035 7045 7085 7407 8397 8910 9410 9420 9973 10523 10570 10600
Run/Standby Pump Option
Weight - Machine kg 6412 6922 6952 6962 7166 8146 8702 9182 9192 9730 10310 10364 10384
Weight - Operating kg 6832 7322 7332 7372 7686 8676 9222 9722 9732 10280 10830 10894 10924
OPC500HE+DQ12
OPC525HE+DQ12
OPC550HE+DQ12
OPC600HE+DQ12
OPC650HE+DQ12
OPC700HE+DQ14
OPC750HE+DQ16
OPC800HE+DQ16
OPC850HE+DQ18
OPC900HE+DQ20
OPC950HE+DQ20
OPC1000HE+DQ20
OPC1100HE+DQ20
Single Pump Option
Weight - Machine kg 7525 7555 7585 7595 7647 8767 9760 9770 10270 10813 10903 10940 10970
Weight - Operating kg 7895 7975 7995 7995 8037 9287 10290 10290 10790 11333 11433 11470 11480
Run/Standby Pump Option
Weight - Machine kg 7812 7842 7872 7882 7926 9046 10072 10082 10582 11120 11210 11264 11294
Weight - Operating kg 8182 8262 8282 8282 8316 9566 10602 10602 11102 11640 11740 11794 11804
(1) Machine weight includes refrigerant charge; operating weight includes refrigerant charge and water volume.
