OPTICHILL Chillers
Chillers
44
Installation & Maintenance : 6564868 08/2008
Commissioning Data
OIL & REFRIGERANT CHARGES - HIGH EFFICIENCY
OPC500HED8 OPC525HED8 OPC550HED8 OPC600HED10 OPC650HED10
Compressor Screw - Twin
Quantity 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
Oil Charge Volume (Total) l 22 + 22 19 + 22 19 + 19 19 + 19 19 + 19
Oil Type Ester Oil
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve (EEV)
Refrigerant Pre Charged R134a
Charge (Total) kg 85 + 85 90 + 85 90 + 90 105 + 105 115 + 115
OPC500HEDQ10 OPC525HEDQ10 OPC550HEDQ10 OPC600HEDQ10 OPC650HEDQ10
Compressor Screw - Twin
Quantity 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
Oil Charge Volume (Total) l 22 + 22 19 + 22 19 + 19 19 + 19 19 + 19
Oil Type Ester Oil
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve (EEV)
Refrigerant Pre Charged R134a
Charge (Total) kg 100 + 100 105 + 100 105 + 105 105 + 105 105 + 105
OIL & REFRIGERANT CHARGES - HIGH EFFICIENCY PLUS
OPC500HE+D8 OPC525HE+D10 OPC550HE+D10 OPC600HE+D10 OPC650HE+D10
Compressor Screw - Twin
Quantity 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
Oil Charge Volume (Total) l 22 + 22 19 + 22 19 + 19 19 + 19 19 + 19
Oil Type Ester Oil
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve (EEV)
Refrigerant Pre Charged R134a
Charge (Total) kg 90 + 90 115 + 105 115 + 115 115 + 115 120 + 120
OPC500HE+DQ12 OPC525HE+DQ12 OPC550HE+DQ12 OPC600HE+DQ12 OPC650HE+DQ12
Compressor Screw - Twin
Quantity 1 + 1 1 + 1 1 + 1 1 + 1 1 + 1
Oil Charge Volume (Total) l 22 + 22 19 + 22 19 + 19 19 + 19 19 + 19
Oil Type Ester Oil
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve (EEV)
Refrigerant Pre Charged R134a
Charge (Total) kg 125 + 125 130 + 125 130 + 130 130 + 130 130 + 130
