D-Link DES-3350SR Standalone Layer 3 Switch
23
logging out. The default for this setting is 10
minutes.
MAC Address Aging
Time <300>
The MAC Address Aging Time specifies the
length of time a learned MAC Address will
remain in the forwarding table without being
accessed (that is, how long a learned MAC
Address is allowed to remain idle). The Aging
Time can be set to any value between 10 and
1,000,000 seconds.
IGMP Snooping
<Disabled>
IGMP Snooping allows the switch to read the
Multicast Group IP address and the
corresponding MAC address from IGMP
packets that pass through the switch. It can be
enabled globally by toggling Disabled to
Enabled.
GVRP Status
<Disabled>
To enable GVRP on the switch globally, toggle
Disabled to Enabled.
Telnet Status
<Disabled>
The Switch can be accessed using Telnet.
Toggle Disabled to Enabled.
Web Status <Disabled>
To enable the Web status, toggle Disabled to
Enabled.
Link Aggregation
Algorithm <Mac
Source>
The Link Aggregation Algorithm can be set to
one of the following: IP Src & Dest, IP
Destination, IP Source, Mac Src & Dest, Mac
Destination, or Mac Source.
RMON Status
<Disabled>
To enable RMON capability, toggle Disabled
to Enabled.
802.1x Status To enable 802.1x port control access on a
global basis, toggle Disabled to Enabled.
Port Description
The Switch supports a port description feature where the user may name various ports on the Switch. To assign names to various
ports, click the Port Description on the Configuration menu:
