D-Link DES-3350SR Standalone Layer 3 Switch

To delete an existing entry, click the selection button in the Delete column on the far right that corresponds to the port you want to

configure. To create a new entry, configure the parameters as desired in the top part of the window above and click the Apply

button. This will add the new string to the SNMP Community Table.

Configure the following for the new SNMP Community entry:

Parameter Description

Community Name Type an alphanumeric string of up to 32

characters that is used to identify members of

an SNMP community. This string is used

like a password to give remote SNMP

managers access to MIB objects in the

switch’s SNMP agent.

View Name Type an alphanumeric string of up to 32

characters that is used to identify the group of

MIB objects that a remote SNMP manager is

allowed to access on the switch. The view

name must exist in the SNMP View Table.

Access Right Use the pull-down menu to select the access

right:

Read_Only − Specifies that SNMP

community members using the community

string created with this command can only

read the contents of the MIBs on the switch.

Read_Write − Specifies that SNMP

community members using the community

string created with this command can read

from and write to the contents of the MIBs on

the switch.

SNMP Host Table

Use the SNMP Host Table to set up trap recipients.

Figure 8 - 13. SNMP Host Table window

To delete an existing entry, click the selection button in the Delete column on the far right that corresponds to the port you want to

remove. To create a new entry, click the Add button, a separate window will appear.

Figure 8 - 14. SNMP Host Table Configuration window

Parameter Description

Host IP Address Type the IP address of the remote

management station that will serve as the
