D-Link DIR-632 [10/116] Hardware overview
![D-Link DIR-632 [10/116] Hardware overview](/views2/1044518/page10/bga.png)
5D-Link DIR-632 User Manual
Section 1 - Product Overview
Hardware Overview
Connections
1 LAN.Ports.(1-8) Connect Ethernet devices such as computers, switches, and hubs.
2 Internet.Port The auto MDI/MDIX Internet port is the connection for the Ethernet cable to the cable or DSL modem.
3 USB USB 1.1/2.0 port for SharePort
TM
Network and WCN support.
4 Reset Pressing the Reset button restores the router to its original factory default settings.
5 Power.Receptor Receptor for the supplied power adapter.
1
2 3
4
5
