D-Link DIR-632 [11/116] Hardware overview
![D-Link DIR-632 [11/116] Hardware overview](/views2/1044518/page11/bgb.png)
6D-Link DIR-632 User Manual
Section 1 - Product Overview
Hardware Overview
LEDs
1 Power.LED A solid light indicates a proper connection to the power supply.
2 Internet.LED A solid light indicates connection on the Internet port. This LED blinks during data transmission.
3 WLAN.LED
A solid light indicates that the wireless segment is ready. This LED blinks during wireless data
transmission.
4 USB.LED A solid light indicated that the USB device is ready. This LED blinks during data transmission.
5 Local.Network’s.LED
A solid light indicates a connection to an Ethernet-enabled computer on ports 1-8. This LED blinks during
data transmission.
1
3
2
4
5
