1D-Link DIR-632 User Manual
Section 1 - Product Overview
Product Overview
Note: Using a power supply with a dierent voltage rating than the one included with the DIR-632 will cause damage and void the warranty for this product.
Package Contents
If any of the above items are missing, please contact your reseller.
DIR-632 Wireless N 8-Port Router
Ethernet Cable
Two Detachable Antennas
Power Adapter
CD-ROM with Manual and Setup Wizard
