Intended Use
The Video Cystoscope is intended to provide optical visualization of (via a video monitor), and therapeutic access to, the Urinary
Tract. The Urinary Tract includes, but is not restricted to, the organs; tissues; and subsystems: Urethra and Bladder.
This instrument is introduced via the urethra when indications consistent with the need for the procedure are observed in adult
and pediatric patient populations.
Never use this endoscope for any purpose other than that for which it has been designed.
This video endoscope contained in this manual can only be used with PENTAX Video Processor, EPK-i series, EPK-p or EPK-
1000.
Notes
Read this owner’s manual before operating, and save the manual for future reference. Failure to read and thoroughly
understand the information presented in this manual, as well as those developed for ancillary endoscopic equipment and
accessories, may result in serious injury including infection by cross contamination to the patient and/or user. Furthermore,
failure to follow the instructions in this manual may result in damage to, and/or malfunction of, the equipment.
This manual describes the recommended procedures for inspecting and preparing the equipment prior to its use and for the
reprocessing and maintenance of the equipment after its use.
It does not describe how an actual procedure is to be performed, nor does it attempt to teach the beginner the proper technique
or any medical aspects regarding the use of the equipment.
It is the responsibility of each medical facility to ensure that only well educated and appropriately trained personnel, who are
competent and knowledgeable about the endoscopic equipment, antimicrobial agents/processes and hospital infection control
protocol be involved in the use and the reprocessing of these medical devices. Known risks and/or potential injuries associated
with flexible endoscopic procedures include, but are not limited to, the following: perforation, infection, hemorrhage, burns and
electric shock.
Current Infection control guidelines require that cystoscopes and other semi-critical medical devices, that normally come into
contact with intact mucous membranes, such as in the urinary tract, must at least be cleaned and high-level disinfected before
clinical use. Only the user can determine if an instrument has undergone appropriate infection control procedures prior to each
clinical use. It must be recognized that infection control practices involve many complex and often controversial issues which are
constantly evolving. PENTAX strongly recommends that user remain informed of the latest federal and local regulations, and
encourages users to follow infection control guidelines developed by various organizations for health care professionals.
If you have any questions regarding any of the information in this manual or concerns pertaining to the safety and/or use of this
equipment, please contact your local PENTAX representative.
Sterility Statement
The instruments identified in this manual are reusable medical devices. Since they are packaged non-sterile, they must be
cleaned and either high-level disinfected or sterilized BEFORE initial use. Prior to each subsequent procedure, they must be
subjected to an appropriate cleaning and either high-level disinfection or sterilization process.
Contraindication
Please consult regional and national health authority recommendations and requirements regarding protocols to follow in order
to reprocess and/or destroy endoscopes that will be used or have been determined to have been used (post procedure) on
patients afflicted with Creutzfeldt-Jacob Disease (CJD or vCJD).
Do not use this product on a patient with untreated acute cystitis/urethritis. Doing so might result in an increase in inflammation
and possible permanent tissue damage.
Conventions
Throughout this manual, the following conventions will be used to indicate a potentially hazardous situation which, if not
avoided;
WARNING
: could result in death or serious injury.
CAUTION
: may result in minor or moderate injury or property-damage.
NOTE
:
may result in property-damage. Also, advises owner/operator about important information on the use of this
equipment.
Prescription Statement
Federal (U.S.A) law restricts this device to sale by or on the order of a physician or other appropriately licensed medical
professional.
