– 51 –
4-2-4-1. Items required for disinfection
• protective garments such as gloves, gowns, face masks, etc. to minimize the
risk of cross contamination.
• disinfecting solution
• sterile water or at least clean potable water
• 70-90% medical grade ethyl or isopropyl alcohol
• basin to immerse the entire endoscope (at least 50 cm in width x 40 cm in
depth x 15 cm in height)
• sterile gauze
• 30 mL syringe
• soaking cap (OE-C9)
• cleaning cap (OF-B155)
• rubber inlet seal (OF-B190)
4-2-4-2. Preparatory Procedure
1) Wear the protective garments.
2) Prepare the basin with disinfectant solution per manufacturer’s instructions
(temperature, concentration).
3) Attach the soaking cap (OE-C9) to the endoscope
4) Ensure the ETO cap (OF-C5) is removed from the endoscope. Remove that, if
attached.
4-2-4-3. Channel disinfection with disinfecting solution
WARNING:
During flushing disinfectant, avoid introduction of air. The presence of air bubbles
could prevent contact of the disinfectant with channel surfaces.
Channel
to be
disinfected
Adapters/
Components to be
attached
Syringe Disinfectant
Rinse
water/Air
Alcohol
Flush
Suction/
Irrigation/
Instrument
Cleaning Cap
OF-B155
30 mL
20 mL or
more
30 mL or
more
10 mL or
more
Rubber inlet Seal
OF-B190
CAUTION:
Always immerse the endoscope during flushing disinfecting solution into the
endoscope channel.
1) Immerse the endoscope in disinfecting solution.
