AUTO BOOSTER
Original Instructions
The AUTO BOOSTER can be connected to an external fuel supply.
As a standard, the machine is supplied with a 33 l container.
You can choose between “one” and “two” -string connection, where
“one”-string only has one supply hose (a) and “two”-string has an
additional return hose (b) - see fi gure.
Please observe the following restrictions to fuel line.
Please observe that in some countries only the “one” string system
is approved.
The fuel hose for the external fuel supply can be lead-in:
1. Through the bottom plate to the oil pump.
2. Through the punch-out pieces in the rear plate to the oil pump.
See foldout at the end of this manual.
3.7 Connecting to exter-
nal fuel supply (AUTO
BOOSTER D)
B
B
A
