Nilfisk SH AUTO 5M [6/33] Description
![Nilfisk SH AUTO 5M [6/33] Description](/views2/1514922/page6/bg6.png)
6
AUTO BOOSTER
Original Instructions
Machine protection
The machine features an over-
current protection and built-in
thermal protection of the motor.
In the event of increased power
consumption (maloperation)
and in the event of excessive
2 Description
This high-pressure hot water washer has been developed for sta-
tionary installation and self service operation within car washing
Section 4 describes how to use the high-pressure hot water wash-
er.
Only use the high-pressure hot water washer for purposes de-
scribed in this manual.
The safety precautions must be observed to prevent damage to the
machine, the surface to be cleaned or severe personal injuries.
2.2 Operation elements See foldout at the end of these operating instructions.
11 Water softening unit (op-
tion)
12 Display (hour counters, er-
ror messages)
13 Brush holder
14 Lance holder
15 Data plate
16 Lifting device
17 Coin selector
18 Assembly box, mains cable
19 "Free operation" switch
20 Heating element, frost pro-
tection
21 Tap (accessory)
22 No Scale, pump/container
23 Adjustment of detergent
concentration
24 Inverter
motor temperature (obstructed
ventilation etc.), the entire
machine will automatically be
disconnected from the mains
supply.
Short circuit protection
The machine is equipped with
a short-circuit protection. In the
event of short-circuits in the
machine, the protective device
will disconnect and a manual
reset is required.
2.1 Application
1 Wash boom / high pressure
hose
2 Main switch
3 Program selector switch
4 Water inlet (only machines
with optional water soften-
ing unit)
5 Thermostat (temperature
adjustment) -
AUTO BOOSTER E
5a Thermostat (temperature
adjustment) -
AUTO BOOSTER D
6 Electric box
7 Water tank
8 Detergent container
9 Fuel container
10 Pressure gauge
